D-204 Marathon Single/Pair Cob/Horse

D-204 Marathon  Crossover

Single or Pair Cob or Horse 15 hands +

The D-204 is an all purpose pair or single vehicle, suitable for CDEs, training and pleasure. When the D-204 is ordered as a dedicated pair carriage it can come with an adjustable independent U shaped shaft to be driven as a single or when ordered as a single carriage with an adapter & pole it is convertible to a pair carriage. The D-204 comes standard with a wide box with a flat passenger or co-driver seat the option of moving the marathon seat to the center. The two rear passenger seats permit this carriage to be suitable for pleasure taking family or friends for cross country drives. The cob weight starts at 525 lbs depending on options, for another choice of a light horse pair marathon please look at the D-185.

Contact Us For Price

  • Bit Calipers Brembo knockoffs) with “no rust” rotors
  • Steel adjustable pole & shafts
  • Choice of pneumatic or hard rubber tires
  • Choice of paint and striping color
  • Marathon bucket seat adjustable front & back

Optional Polished Stainless Steel

Stainless steel, chrome rolled steel (SAE 5140), is not only pretty, resist scratches and abrasions but is also lighter and stronger than low carbon rolled steel (SAE 1010).

“Stainless steel (chrome rolled steel) has about 3X the yield strength of low carbon rolled steel.  Thus, for any given desired strength that is needed for an application, (i.e. shafts, or frame parts of a carriage), you can use a thinner gauge (and hence lower weight) of chrome rolled steel when compared to carbon steel. The mistake that I noted in the past was that most carriages were “over-built” in my estimation, by using the same gauge for both chrome rolled and low carbon steel.   To be sure, the chrome rolled units were much stronger, but I never felt that the extra “crash and burn” durability warranted the heavier than necessary weight.  I don’t mind training heavy, but I sure do like to compete light. By using a thinner gauge stainless steel you can maintain or increase strength and be lighter at the same time, the best of both worlds.”  Ken Messner & “Welding Principles and Practices” by Raymond Sacks.

There are multiple possibilities to add stainless steel to your carriage. The following are several options for you to consider. If you don’t see a specific item you would like please let us known.

NOTE:  If  you would like stainless to reduce weight but choose to have it painted vs. polished the pricing is reduced.

The first option and most common, is adjusted by a small hand wheel which the navigator or groom operates. A small brake master cylinder provides hydraulic pressure to a small motorcycle type caliper which engages a brake disk attached to the fifth wheel.  The second option of the hydraulic fifth wheel brake pedal is operated by the driver by means of an extra brake pedal that operates a small master cylinder to provide hydraulic pressure to a small motorcycle type caliper which engages a brake disk attached to the fifth wheel. This option, like the hand wheel operated by the navigator/groom is quite effective, the braking action is instant when the pedal is depressed and instant off when the pedal is released.

The wheel and pedal operated 5th wheel brakes are available together..

The “manometer’ permits you to set the desired amount of pressure on the fifth wheel for both the pedal operated by the driver or the hand wheel operated by the navigator.

The pedal operated hydraulic fifth wheel brake, which can help provide a straight rein back in dressage, is also available on Presentation carriages. Maybe just may be enough help to bring home the blue!!!

Contact us for custom-fitted carriage quote! We will expertly match features tailored to you and your equine partners’ needs.

*Carriage prices are subject to change and do not include delivery to final destination from Windsor, SC, or State sales tax, where applicable.
